Fibreglass Acrylic Filter Bag With Disc Bottom
  • Fibreglass Acrylic Filter Bag With Disc Bottom
  • Fibreglass Acrylic Filter Bag With Disc Bottom
  • Fibreglass Acrylic Filter Bag With Disc Bottom
  • Fibreglass Acrylic Filter Bag With Disc Bottom
  • Fibreglass Acrylic Filter Bag With Disc Bottom
  • Fibreglass Acrylic Filter Bag With Disc Bottom

Fibreglass Acrylic Filter Bag With Disc Bottom

Place of Origin china
Brand Name filter
Model Number FLT-FB-269
Product Details
Usage:
Dust Filter,Air Filter,Liquid Filter,dust Collector,Liquid Filtration
Type:
Pocket Filter,Mesh Filter Bag,Vacuum Cleaner Paper Bag,Dust Filter Bag,Non-woven Filter
Material Of Bag:
Aramid,Non-woven,Polyester,PTFE,Fiberglass
Application:
Industry Dust Collector,cement Plant,Dust Collector Bag House,asphalt Mix,Industrial Dust Removal
Applicable Industries:
Manufacturing Plant,Energy & Mining,Construction Works
Product Name:
NomexFilter Bag,filter Bag,Nomex,jet Dust Filter,Polyester Anti-Static Needle Felt Filter Bag
Size:
Custiomized
Material:
Polyester Fiber,Aramid,aramid Nomex Metamax,PET
Package:
Polybags/cartons/customized
Feature:
Dust Collection,High Filtration Accuracy,Eco-Friendly,Heat Resistant,High Quality
Name:
NOMEX Dust Filter Bag,Non-woven Pocket Air Filter Bag,250 Micron Bag Filter Cage Aramid Filter Bag
Sample:
Available And Free
Oem:
Welcomed
Keyword:
Aramid Filter Bag,nomex Filter Bag For Steel Plant
Highlight:

Disc Bottom Acrylic Filter Bag

,

250 Micron Acrylic Filter Bag

,

Disc Bottom Aramid Filter Bag

Payment & Shipping Terms
Minimum Order Quantity
50pcs
Price
Negotiable
Packaging Details
carton
Delivery Time
7 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100000pcs per month
Product Description

Polyester Nomex PP Acrylic Fibreglass Filter Bag:


Description:

Materials:

Needle punched Polyester,Arcylic,Aramid,PPS,P84,PTFE,Fibreglass felts for filtration are exhibiting excellent performance under wet,acid,alkali and normal-temperature and high temperature environments.
Proper Temperature:

The melting temperature of all material is as high as 90oc to 300oc.
Filter Bag Top:
Carbonsteel snapband&SS snapband.
Bottom:Reforcement 100mm or Disc.
Size:Customized.


Technical Specification:

Raw materials
of the filter material
Temperature
Property of the filter material
& the suitable industrial conditions
Application field and
industrial condition
Polypropylene (PP)
900C
Suitable for the condition with continuous working temperature less than 900C & short time temperature less than 1000C. The oxidation resistance of the material is ordinary. Suitable PH range is 1to 14. The resistance of hydrolysis of the material is good.
Suitable for the dust collection of sugar production, chemical fertilizer plants, electroplating, pesticide plant, etc
polyacrylonitrile(AC)
1100C
Suitable for the condition with continuous working temperature less than 1100C & short time temperature less than 1150C. The oxidation resistance of the material is ordinary. Suitable PH range is 6 to 13.
Relative humidity<5%
Suitable for the dust collection of detergent production, pulverized coal plant, etc
homopolyacrylonitrile(DT)
1250C
Suitable for the condition with continuous working temperature less than 1250C & short time temperature less than 1400C. The oxidation resistance of the material is ordinary. Suitable PH range is 3 to 11
Relative humidity<30%
Suitable for the dust collection of detergent production, garbage incineration, asphalt, spray dryer, coal mill, power plant, etc.
Polyester (PE)
1500C
Suitable for the condition with continuous working temperature less than 1300C & short time temperature less than 1500C. The oxidation resistance of the material is good.
The acid-base resistance is ordinary. Suitable PH range is 4 to 12.
Relative humidity<4%
The expected lifetime depends on the moisture content of the flue gas when the working temperature is high.
Suitable for the dust collection of mine, lime cement production, raw cement, grinding machine, packaging and other process, continuous casting and sintering, ironmaking processes of Iron and steel industry , alumina conveying, electrolytic aluminum production, non-ferrous metal smelting plant, wood processing, food processing, pharmaceutical and other industries
polyphenylene sulfide
(PPS)
1600C
Suitable for the condition with continuous working temperature less than 1600C & short time temperature less than 2000C. The oxidation resistance of the material is not good. The resistance to acid-base is good. Suitable PH range is 1 to 14
Relative humidity>30%
Suitable for the dust collection of flue gas of coal-fired boilers, garbage incineration, metal smelting, chemical industry , etc.
polyamide (NO)
2000C
Suitable for the condition with continuous working temperature less than 2040C & short time temperature less than 2400C. The oxidation resistance of the material is ordinary.
PH range is 4 to 12.
Relative humidity<10%
The performance of the material depends on the moisture content of the flue gas when the working temperature is high.
Suitable for the dust collection of flue gas of asphalt-mixing, non-ferrous metal smelting, ceramics, glass, kiln head of cement industry (grate cooler), steel blast, etc.
polyimide(PI/P84)
2200C
Suitable for the condition with continuous working temperature less than 2200C & short time temperature less than 2600C. The oxidation resistance of the material is ordinary.
PH range is 3 to 13.
Relative humidity<25%
Suitable for the dust collection of the corrosive flue gas of Chemical plant, metal melting, garbage incineration, cement preheater and coal boiler, etc.
polyfluortetraethylene(PTFE)
2500C
Suitable for the condition with continuous working temperature less than 2500C & short time temperature less than 2800C. The material have good resistance for all the chemical corrosion
PH range is 1 to 14
Relative humidity>30%
The material has good ash removal performance.
Suitable for the dust collection of the highly temperature and high corrosive flue gas of Chemical industry, coal boiler, garbage incineration, non-ferrous metal smelting plant, etc.
Fiberglass (FG)
2600C
Suitable for the condition with continuous working temperature less than 2600C & short time temperature less than 2800C. The oxidation resistance of the material is ordinary. Suitable PH range is 4 to 9
Relative humidity55%
Suitable for the dust collection of the highly temperature flue gas of, Cement production, coal boiler, garbage incineration, steelmaking furnace, blast furnace gas production, the ferroalloy furnace, etc


Producing Process:



Install Diagram:


Applications:





Production Features:

1. Various material: Polyester(PE), Polypropylen(PP), Aramid, P84, Acrylic, PPS, Fiberglass, PTFE,Nomex,FMS etc.
2. Strong intensity.
3. Excellent anti-abrasion,good finishing treatment.
4. Good raw material, competitive price.
5. High filtration efficiency .
6. Fast delivery.
7. Size can be customized.
8. Factory manufacturer could contol quality and price.
9. Strict quality inspection and contol.
10. Professional designer team to match with your operating condition.

More Production:




Packaging & Delivery:




Foreign Trade Team:






Exhibization:


Certificate:




Competitive Advantages:



1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.

5. We offer high quality products at competitive price in quick delivery



Shipping Details:



SHIPPING

(Normally arrive port time in working days)

Destination Express/Courier SHIP BY SEA SHIP BY AIR SHIP BY EMS
DHL/FEDEX/UPS/TNT
North America 3~7 days 15~24 days 5~7 days 10~12 days
South America 3~7 days 15~25 days 5~7 days 10~12 days
European Countries 3~7 days 20~30 days 5~7 days 10~12 days
Africa Countries 3~7 days 40~50 days 5~7 days 10~12 days
The Middle East 3~7 days 15~25 days 5~7 days 10~12 days
Australia 3~7 days 10~15 days 5~7 days 10~12 days
