PP(Polypropylene) monofilament mesh Liquid Filter Bag
Description:
Item name: Polypropylene filter bag
Material: Polypropylene monofilament mesh
Micron rating:0.5μm~250um
Construction: Hot-melt or sewing thread.
Collar type: Steel ring or plastic ring
Application:
Chemical industry, adhesive industry, paints industry, petrochemical industry, resin industry, cosmetic industry, etc.
We can produce filter bags to meet your specific requirements.
Liquid Filter Bag Technical Data
Bag Construction | Filter Media | Micron(μm) | Top Design | Bottom Design |
Sewing Thread | | 1,5,10,25,50,80,100,125, | Zinc-plated | Round |
Filter Bag Specification
Type | Flow rate(m3/h) | Filtration Area(m2) | Volume (L) | Size (Diameter X Length) | |
#1 | 20 | 0.25 | 8 | 7" x 17" (180mm x410mm) | |
#2 | 40 | 0.50 | 7 | 7" x 32" (180mm x 810mm) | |
#3 | 6 | 0.09 | 1.3 | 4" x 9" (108mm x 230mm) | |
#4 | 12 | 0.16 | 2.5 | 4" x 15" (108mm x 380mm) | |
*Size could be on your request. |
Filter Bag Material Performance Table
Filter Media | Temp.(oC) | Strong Acid | Weak Acid | Strong Alkaline | Weak Alkaline | Oils and Fats | Glycol Ether | Organic Solution | Water Microorganism | Aromatic |
PE | 150~170 | √ | √ | √ | √ | √ | √ | |||
PO/PP | 90~110 | √ | √ | √ | √ | √ | √ | √ | √ | |
NMO | 150~170 | √ | √ | √ | √ | √ | ||||
PTFE | 250~300 | √ | √ | √ | √ | √ | √ | √ | √ | √ |
Filter Diameter Reference Table
Mesh | 30 | 35 | 40 | 45 | 50 | 60 | 70 | 80 | 100 | 120 | 140 | 170 | 200 | 230 | 270 | 325 | 400 | 425 | 500 | 625 | 800 | 1250 | 2500 | 6250 | 12500 |
μm | 595 | 500 | 420 | 354 | 297 | 250 | 210 | 177 | 149 | 125 | 105 | 88 | 74 | 63 | 53 | 44 | 37 | 33 | 25 | 20 | 15 | 10 | 5 | 2 | 1 |
Produce Workshop:
Competitive Advantages:
1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.
5. We offer high quality products at competitive price in quick delivery.
Shipping Details:
SHIPPING (Normally arrive port time in working days) | ||||
Destination | Express/Courier | SHIP BY SEA | SHIP BY AIR | SHIP BY EMS |
DHL/FEDEX/UPS/TNT | ||||
North America | 3~7 days | 15~24 days | 5~7 days | 10~12 days |
South America | 3~7 days | 15~25 days | 5~7 days | 10~12 days |
European Countries | 3~7 days | 20~30 days | 5~7 days | 10~12 days |
Africa Countries | 3~7 days | 40~50 days | 5~7 days | 10~12 days |
The Middle East | 3~7 days | 15~25 days | 5~7 days | 10~12 days |
Australia | 3~7 days | 10~15 days | 5~7 days | 10~12 days |
Contact Us at Any Time
