Anhui Filter Environmental Technology Co.,Ltd.
Product Details:
Payment & Shipping Terms:
|
Product Name: | PTFE Film-coated Filter Bag | Size: | Customized |
---|---|---|---|
Usage: | Dust Filter,steel,Air Filter | Type: | Pocket Filter,pulse Jet,reverse Air,used To Steel Works Equipments |
Material Of Bag: | Fiberglass,PE,Non-woven,PTFE | Material: | PTFE,Fiberglass,Nomex,Fiberglass / P84 / PTFE / Nomex,Polyester |
Application: | Industry Dust Collector,dust Filter Bag For Cemet Factory And So On,baghouse Dust Collector | Shape: | Round Or Customized |
Thickness: | 1.8-2.8mm | Bag Top Type: | Carbonsteel Snapband Or SS304 Snapband |
Temperature: | 130-300 Deg. | Samples: | Available |
Weight: | 750gsm | Scrim: | PTFE |
High Light: | 750gsm PTFE Filter Bag,PTFE Film Coated Filter Bag,Corrosion Resistance PTFE Filter Bag |
High temperature corrosion resistance 750gsm PTFE needle felt:
Description:
Material:PTFE filter cloth
Weight: 750GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138, Φ 152, Φ 158 etc. We make it as your requirements.
Length: 1000mm~8000mm. We make is as your requirements.
Specification:
Fibre | PTFE |
Scrim | PTFE |
Weight(G/M2) | 750 |
Thickness (mm) | 1.27 |
Width (mm) | ≤ 2.2 |
Length | 50m/roll |
Finish treatment | Singeing,Calendering,Heat-set,PTFE-coating,Water and Oil Repellent,PTFE membrane Coating. |
Air permeability (L/dm2*min@200pa): | 5.47 |
Tensile strength (N/5× 20cm) | Warp:>700 Weft:>600 |
Tensile elongation (%): | Warp:<30 Weft:<45 |
Temperature (ºC): | Continue: 240 Instant: 280 |
Application | Mainly used in Combustion,Coal burning boiler,Waster incineration,Carbon black producing. |
Product Feature:
1. Be composed of 100% pure PTFE.
2. It can operate at 240oC continuously.
3. Acid and alkali resistance,corrosion resistance and have strong chemical stability(0-14PH)
4. It can be used under high humidity environment.
5. Low shrinkage rate even if under high temperature.
Application:
1. Asphalt mixing plant.
2. Biomass power stations.
3. Chemical and pharmaceutical industry.
4. High temperature dedusting.
5. Coal-fired power stations.
6. Food industry.
7. Non-ferrous metal and steel production.
8. Cement,gypsum and lime industry.
9. Thermal waste treatment.
Producing Process:
Install Diagram:
Applications:
1. Asphalt mixing plant.
2. Biomass power stations.
3. Chemical and pharmaceutical industry.
4. High temperature dedusting.
5. Coal-fired power stations.
6. Food industry.
7. Non-ferrous metal and steel production.
8. Cement,gypsum and lime industry.
9. Thermal waste treatment.
More Production:
Packaging & Delivery:
Foreign Trade Team:
Exhibization:
Customer Visit:
Certificate:
Shipping Details:
SHIPPING (Normally arrive port time in working days) |
||||
Destination | Express/Courier | SHIP BY SEA | SHIP BY AIR | SHIP BY EMS |
DHL/FEDEX/UPS/TNT | ||||
North America | 3~7 days | 15~24 days | 5~7 days | 10~12 days |
South America | 3~7 days | 15~25 days | 5~7 days | 10~12 days |
European Countries | 3~7 days | 20~30 days | 5~7 days | 10~12 days |
Africa Countries | 3~7 days | 40~50 days | 5~7 days | 10~12 days |
The Middle East | 3~7 days | 15~25 days | 5~7 days | 10~12 days |
Australia | 3~7 days | 10~15 days | 5~7 days | 10~12 days |
