Polypropylene Nylon Monofilament Mesh Liquid Filter Bags Customized
Place of Origin:
china
Brand Name:
Filter
Model Number:
liquid filter bag
Product Details
Place of Origin:
china
Brand Name:
Filter
Model Number:
liquid filter bag
Minimum Order Quantity:
Negotiable
Price:
Negotiable
Standard Packaging:
carton
Delivery Time:
7 days
Payment Terms:
L/C, D/A, D/P, T/T, Western Union,
Supply Ability:
100000pcs per month
Specifications
Usage:
Liquid Filter/Water Liquid Filter/Oil Filter
Type:
Liquid Filter Bag/Mesh Filter Bag
Material of bag:
Nylon,PP,PE,Nmo
Application:
Water,coffee,Liquid Filteration,industry Dust Collector,dust Filter
Size:
Custiomized
Product name:
Liquid Filter Bag
Micron rating:
5 10 25 50 75 100 150 200 300 400 500 Micron
Sample:
Avaliable
Top:
String,SS304 RING Or Plasic Ring
Body:
Sewing Thread Or Hot-melt
Bottom:
Sewing Thread Or Hot-melt
Highlight:
Nylon Monofilament Mesh Liquid Filter Bag
,Polypropylene Mesh Liquid Filter Bag
,Customized Mesh Liquid Filter Bag
Product Description
Polypropylene/Nylon Monofilament Mesh/ Polyester Multifilament Mesh/Liquid Filter Bags:
1. The filter mesh widely used in all kinds of filtration and separation, such as:
1. air filter mesh in air conditioner filter.
2. liquid filter mesh for milk, juice, cheese, soya bean ect.
3. flour, solid mesh for milling.
4. We can deep produce it into filter disc and filter strainers.
5. hydrocarbon extraction.
1. air filter mesh in air conditioner filter.
2. liquid filter mesh for milk, juice, cheese, soya bean ect.
3. flour, solid mesh for milling.
4. We can deep produce it into filter disc and filter strainers.
5. hydrocarbon extraction.
2. Production Description:

We produce Polyester,Nylon,Polypropylene liquid filter bag.
We supply different micron liquid filter bag and custom size for customer.

We can custom different size Plastic ring and Steel ring according to your requirements.

We can custom different bottom such as U-type bottom,V-type bottom
according to your requirements.
3. The Chemical Resistance of Liquid Filter Bag:
| Product Name | Liquid Filter Bags | ||
| Material Available | Nylon (NMO) | Polyester (PE) | Polypropylene (PP) |
| Maximum Operating Temperature | 275-300° F (135-149° C) | 275-325° F (135-162° C) | 200-220° F (93-104° C) |
|
|
5,10,25, 50, 100, 150, 200, 300, 400, 500, 600, or 5-2000um | 0.5, 1, 3, 5, 10, 25, 50, 75, 100, 125, 150, 200, 250, 300 | 0.5, 1, 3, 5, 10, 25, 50, 75, 100,125, 150, 200, 250, 300 |
|
Size
|
1 #: 7" x 16" (17.78 cm x 40.64 cm)
2 #: 7" x 32" (17.78 cm x 81.28 cm)
3 #: 4" x 8.25" (10.16 cm x 20.96 cm)
4 #: 4" x 14" (10.16 cm x 35.56 cm)
5 #: 6 " x 22" (15.24 cm x 55.88 cm)
Customized size
|
||
|
Filter Bag Area(m²) /
Filter Bag Volume (Liter)
|
1#: 0.19 m² / 7.9 Liter
2#: 0.41 m² / 17.3 Liter
3#: 0.05 m² / 1.4 Liter
4#: 0.09 m² / 2.5 Liter
5#: 0.22 m² / 8.1 Liter
|
||
| Collar Ring | Polypropylene ring/Polyester ring/Galvanized steel ring/
Stainless steel ring/Rope
|
||
| Remarks | OEM: support
Customized item: support
|
||
| The Chemical Resistance Of Liquid Filter Bag | |||
| Fiber Material | Polyester (PE) | Nylon (NMO) | Polypropylene (PP) |
| Abrasion Resistance | Very Good | Excellent | Very Good |
| Weakly Acid | Very Good | General | Excellent |
| Strongly Acid | Good | Poor | Excellent |
| Weakly Alkali | Good | Excellent | Excellent |
| Strongly Alkali | Poor | Excellent | Excellent |
| Solvent | Good | Good | General |
4. Characteristic nylon mesh bag/drawstring mesh bag:
* High Elongation.
* Excellent alkaline resistance.
* It has a working temperature of up to 120 degrees ºC.
* Smooth filament, immersion resistance,no material drop off.
* Stable chemical and physical properties
* Excellent alkaline resistance.
* It has a working temperature of up to 120 degrees ºC.
* Smooth filament, immersion resistance,no material drop off.
* Stable chemical and physical properties
5. Producing Process(Air Filter Bag and Liquid Filter Bag):

6. Exhibization:

7. Certificate:
