Aluminum Industry Dust Collector Filter Bags / OEM Polyester Filter Bag

Place of Origin JIANG SU
Brand Name Filter
Model Number FILTER BAG
Product Details
Material:
Polyester Anti-static Filter Cloth
Usage:
Dust Filter, Air Filter, Industry Dust Collector
Type:
Ocket Filter, Mesh Filter Bag, Circular Size Filter Bag, Polyester Dust Filter Bag, Fabric Dust Collector
Size:
Custiomized
Application:
Industry Dust Collector,Dust Filter,Bag House Filter,Liquid-solid Separation,Pocket-type Dust Collector
Working Temperature:
130-150℃
Thickness:
1.9-2.5 Mm
Feature:
High Efficiency,Alkaline Resistant,Large Dust Collection,High Quality
High Light:

polyester filter bag

,

industrial dust collector bags

Payment & Shipping Terms
Minimum Order Quantity
Negotiate
Price
Negotiable
Packaging Details
carton or woven bag
Delivery Time
3~15 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
50000pcs per month
Product Description

Custom High Quantity Polyester Filter Bag for Aluminum Industry



Description:



Material: Polyester anti-static repellent Needle Felt
Weight: 450GSM~550GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138,Φ 152, Φ 158 etc. We make it as your requirements.
Length: 1000mm~8000mm. We make is as your requirements.



Technical Parameters:



Fibre Polyester
Scrim Polyester
Weight(G/M2) 450~550
Thickness (mm) 2.0
Width (mm) ≤ 2.2
Length 50m/roll
Finish treatment Singeing, Calendering, mixing lead static fibre or stripe lead static fibre Treatment.
Air permeability (L/m2/S): 120
Tensile strength (N/5× 20cm) Warp:>1000 Weft:>1100
Tensile elongation (%): Warp:<35 Weft:<55
Temperature (ºC): Continue: 120 Instant: 150
Surface Resistance(Ω.cm) 103~108
Anti-acid Middle
Anti-alkali Middle
Anti-abrasion Excellent
Hydrolytic stability Middle
Application Mainly used in food and beverage industry,pharmaceutical industry,non-ferrous metallurgy,chemcial plant,building section and mining industry,power plant etc.



Production Features:



1.Various material: Polyester(PE), Polypropylen(PP), Aramid, P84, Acrylic, PPS, Fiberglass, PTFE,Nomex,FMS etc.
2.Strong intensity.
3.Excellent anti-abrasion,good finishing treatment.
4.Good raw material, competitive price.
5.High filtration efficiency .
6.Fast delivery.
7.Size can be customized.
8.Factory manufacturer could contol quality and price.
9.Strict quality inspection and contol.
10.Professional designer team to match with your operating condition.



Application:



1. Food and Beverage Industry.

2. Pharmaceutical Industry.

3. Non-ferrous Metallurgy.

4. Chemcial Plant.

5. Building Section and Mining Industry.

6. Cement Plant.

7. Power Plant.

8. Steel Plant.



Making method:

Our bags are sewn with 3 - needle chain stitch to ensure seam integrity. Top constructions consist of snap band, flange top, ring top, soft cuffs or raw edge. Bottom removal bags are constructed with a raw top or soft cuff. Top and bottom removal bag bottoms have disc bottoms that are sewn using an overlock (surge) stitch or lock stitch. A wear strip or custom skirts is attached to the bottom portion of the bag to prevent premature wear from bag-to-bag and bag-to-cage abrasion.



Packaging & Delivery:



Aluminum Industry Dust Collector Filter Bags / OEM Polyester Filter Bag 0



Competitive Advantages:



1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.

5. We offer high quality products at competitive price in quick delivery.



Shipping Details:



SHIPPING

(Normally arrive port time in working days)

Destination Express/Courier SHIP BY SEA SHIP BY AIR SHIP BY EMS
DHL/FEDEX/UPS/TNT
North America 3~7 days 15~24 days 5~7 days 10~12 days
South America 3~7 days 15~25 days 5~7 days 10~12 days
European Countries 3~7 days 20~30 days 5~7 days 10~12 days
Africa Countries 3~7 days 40~50 days 5~7 days 10~12 days
The Middle East 3~7 days 15~25 days 5~7 days 10~12 days
Australia 3~7 days 10~15 days 5~7 days 10~12 days
