High Strength High Temperature 550gsm PPS Filter Bags With PTFE Membrane For Cement Industry
  • High Strength High Temperature 550gsm PPS Filter Bags With PTFE Membrane For Cement Industry
  • High Strength High Temperature 550gsm PPS Filter Bags With PTFE Membrane For Cement Industry
  • High Strength High Temperature 550gsm PPS Filter Bags With PTFE Membrane For Cement Industry

High Strength High Temperature 550gsm PPS Filter Bags With PTFE Membrane For Cement Industry

Place of Origin jiangsu
Brand Name Filter
Model Number PTFE filter bag
Product Details
Product Name:
PPS With PTFE Membrane Filter Bag
Size:
Customized
Usage:
Dust Filter,steel,Air Filter
Type:
Pocket Filter,pulse Jet,reverse Air,used To Steel Works Equipments
Material Of Bag:
Fiberglass,PE,Non-woven,PTFE
Material:
PTFE,Fiberglass,Nomex,Fiberglass / P84 / PTFE / Nomex,Polyester
Application:
Industry Dust Collector,dust Filter Bag For Cemet Factory And So On,baghouse Dust Collector
Shape:
Round Or Customized
Thickness:
1.8-2.8mm
Bag Top Type:
Carbonsteel Snapband Or SS304 Snapband
Temperature:
130-300 Deg.
Samples:
Available
Highlight:

ptfe membrane filter bags

,

550gsm pps filter bags

,

High Strength PTFE Filter Bag

Payment & Shipping Terms
Minimum Order Quantity
50pcs
Price
Negotiable
Packaging Details
Carton or Woven Bag
Delivery Time
3~15 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union
Supply Ability
Supply 10000pcs filter bags per month
Product Description

PPS with PTFE membrane Filter Bag



Description:



Material:PPS Needle Felt
Weight: 450GSM~550GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138, Φ 152, Φ 158 etc. We make it as your requirements.
Length: 1000mm~8000mm. We make is as your requirements.



Specification:



Fibre PPS
Scrim PPS
Weight(G/M2) 450~550
Thickness (mm) 2.2
Width (mm) ≤ 2.2
Length 50m/roll
Finish treatment Singeing,Calendering,PPS dipping treatment,with PTFE membrane or oil&water repellent treatment..
Air permeability (m3/m2/min): 6~10
Tensile strength (N/5× 20cm) Warp:>900 Weft:>1200
Tensile elongation (%): Warp:<35 Weft:<50
Temperature (ºC): Continue: 170 Instant: 210
Anti-acid Excellent
Anti-alkali Excellent
Anti-abrasion Excellent
Hydrolytic stability Excellent





Features:



1.High efficient filtration level.

2.Depth type filtration.

3.Wide range of chemically compatible media.

4.High temperature resistance.

5.High flow efficiency.

6.High air to cloth ratio.

7.Various coatings are available.





Applications:



Coal - Fired Boilers bag houses Calciners / Catalysts.

Municipal Solid Waste Boilers and Waste incinerator.

Electric power plant Electrolysis and other Specialty membranes.

Waste to energy Iron and non ferrous Metal Industry.





Making method:



Our bags are sewn with 3 - needle chain stitch to ensure seam integrity. Top constructions consist of snap band, flange top, ring top, soft cuffs or raw edge. Bottom removal bags are constructed with a raw top or soft cuff. Top and bottom removal bag bottoms have disc bottoms that are sewn using an overlock (surge) stitch or lock stitch. A wear strip or custom skirts is attached to the bottom portion of the bag to prevent premature wear from bag-to-bag and bag-to-cage abrasion.





Packaging & Delivery:



High Strength High Temperature 550gsm PPS Filter Bags With PTFE Membrane For Cement Industry 0





Competitive Advantages:



1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.

5. We offer high quality products at competitive price in quick delivery.





Shipping Details:



SHIPPING

(Normally arrive port time in working days)

Destination Express/Courier SHIP BY SEA SHIP BY AIR SHIP BY EMS
DHL/FEDEX/UPS/TNT
North America 3~7 days 15~24 days 5~7 days 10~12 days
South America 3~7 days 15~25 days 5~7 days 10~12 days
European Countries 3~7 days 20~30 days 5~7 days 10~12 days
Africa Countries 3~7 days 40~50 days 5~7 days 10~12 days
The Middle East 3~7 days 15~25 days 5~7 days 10~12 days
Australia 3~7 days 10~15 days 5~7 days 10~12 days
