Place of Origin | jiangsu |
Brand Name | Filter |
Model Number | filter bag |
PTFE(Teflon) Filter Bag:
Description:
Material:PTFE filter cloth
Weight: 750GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138, Φ 152, Φ 158 etc. We make it as your requirements.
Length: 1000mm~8000mm. We make is as your requirements.
Technical Parameters:
Fibre | PTFE |
Scrim | PTFE |
Weight(G/M2) | 750 |
Thickness (mm) | 1.27 |
Width (mm) | ≤ 2.2 |
Length | 50m/roll |
Finish treatment | Singeing,Calendering and PTFE dipping treatment. |
Air permeability (m3/m2/min): | 5.47 |
Tensile strength (N/5× 20cm) | Warp:>908 Weft:>1026 |
Tensile elongation (%): | Warp:<35 Weft:<50 |
Temperature (ºC): | Continue: 250 Instant: 280 |
Application | Mainly used in Combustion,Coal burning boiler,Waster incineration,Carbon black producing. |
Production Features:
Making method:
Our bags are sewn with 3 - needle chain stitch to ensure seam integrity. Top constructions consist of snap band, flange top, ring top, soft cuffs or raw edge. Bottom removal bags are constructed with a raw top or soft cuff. Top and bottom removal bag bottoms have disc bottoms that are sewn using an overlock (surge) stitch or lock stitch. A wear strip or custom skirts is attached to the bottom portion of the bag to prevent premature wear from bag-to-bag and bag-to-cage abrasion.
Application:
1. Combustion,Coal burning boiler.
2. Waster incineration.
3. Carbon black producing.
Packaging & Delivery:
Competitive Advantage:
1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.
5. We offer high quality products at competitive price in quick delivery.
RFQ
Q1: Are you factory or trading company?
We are manufacturer professional in fiberglass products.
Q2: What's your products ranges ?
1.Fiberglass yarn (E glass, C glass, Texturized yarn);
2.Fiberglass mesh & self-adhesive mesh tape;
3.Industrial fabric & texturized fabric;
4.Coated woven
5.Finished product (fire blanket & filter bag and others)
Q3: Can you supply the sample?
Yes, we can. We could supply small sample free at first time.
Freight collect.
Q4: Do you pass some factory audit or get any certification?
We are gold supplier of Made-in-China and get BV certification.
Our products have passed RoHS.
Q5. What is your packing?
It depends on products and your requirement.
1.Nude pack: PVC bag;
2.PVC bag with pallet;
3.Carton with pallet;If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q6. What is your terms of payment?
30-50% T/T in advance, balance before delivery/against the copy of B/L. We'll show you the photos of the products and packages before you pay the balance/delivery.
Shipping Details:
SHIPPING (Normally arrive port time in working days) |
||||
Destination | Express/Courier | SHIP BY SEA | SHIP BY AIR | SHIP BY EMS |
DHL/FEDEX/UPS/TNT | ||||
North America | 3~7 days | 15~24 days | 5~7 days | 10~12 days |
South America | 3~7 days | 15~25 days | 5~7 days | 10~12 days |
European Countries | 3~7 days | 20~30 days | 5~7 days | 10~12 days |
Africa Countries | 3~7 days | 40~50 days | 5~7 days | 10~12 days |
The Middle East | 3~7 days | 15~25 days | 5~7 days | 10~12 days |
Australia | 3~7 days | 10~15 days | 5~7 days | 10~12 days |
