Non - Woven Nomex Filter Cloth For Dust Colletor Bag 500~550 G/Sqm
  • Non - Woven Nomex Filter Cloth For Dust Colletor Bag 500~550 G/Sqm
  • Non - Woven Nomex Filter Cloth For Dust Colletor Bag 500~550 G/Sqm
  • Non - Woven Nomex Filter Cloth For Dust Colletor Bag 500~550 G/Sqm
  • Non - Woven Nomex Filter Cloth For Dust Colletor Bag 500~550 G/Sqm

Non - Woven Nomex Filter Cloth For Dust Colletor Bag 500~550 G/Sqm

Place of Origin Jiangsu
Brand Name Filter
Model Number Industrial Filter Cloth
Product Details
Usage:
Air Filter,Powder Filter
Type:
Non-woven Filter,Filter Felt,filter Cloth
Material:
Nomex/Aramid
Weight:
500~550 G/sqm
Size:
Custiomized
Name:
Non Woven Nomex Filter Cloth
High Light:

bag filter cloth material

,

fiberglass filter cloth

Payment & Shipping Terms
Minimum Order Quantity
Negotiate
Price
Negotiable
Packaging Details
plastic film
Delivery Time
3~15 days
Payment Terms
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability
100000 square meters per month
Product Description

Factory Manufacture Non-woven Nomex Filter Cloth for Dust Colletor Bag



Description:



Material:Nomex(Aramid)Needle Felt
Weight: 450GSM~550GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138, Φ 152, Φ 158 etc. We make it as your requirements.
Length: 1000mm~8000mm. We make is as your requirements.



Technical Parameters:



Fibre Aramid
Scrim Aramid
Weight(G/M2) 450~550
Thickness (mm) 2.2
Width (mm) ≤ 2.2
Length 50m/roll
Finish treatment Singeing, Calendering, Heat-set
Air permeability (L/m2/s): 120~200
Tensile strength (N/5× 20cm) Warp:>1000 Weft:>1200
Tensile elongation (%): Warp:<50 Weft:<55
Temperature (ºC): Continue: 204 Instant: 240
Anti-acid Excellent
Anti-alkali Excellent
Anti-abrasion Excellent





Making method:

Our bags are sewn with 3 - needle chain stitch to ensure seam integrity. Top constructions consist of snap band, flange top, ring top, soft cuffs or raw edge. Bottom removal bags are constructed with a raw top or soft cuff. Top and bottom removal bag bottoms have disc bottoms that are sewn using an overlock (surge) stitch or lock stitch. A wear strip or custom skirts is attached to the bottom portion of the bag to prevent premature wear from bag-to-bag and bag-to-cage abrasion.



Production Features:



1.High temperature resistance.
2.Good anti-acid/anti-alkali capacity.
3.Excellent anti-abrasion capacity.
4.High filtration efficiency.
5.Good raw material, competitive price.
6.Fast delivery.
7.Size can be customized.



Application:



1. Asphalt mixing plant.

2. Biomass power stations.

3. Chemical and pharmaceutical industry.

4. High temperature dedusting.

5. Coal-fired power stations.

6. Food industry.

7.Non-ferrous metal and steel production.

8.Cement,gypsum and lime industry.

9.Thermal waste treatment.



Packaging & Delivery:



Non - Woven Nomex Filter Cloth For Dust Colletor Bag 500~550 G/Sqm 0



Competitive Advantages:



1. 100% custom pass guaranteed.

2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.

3. Flexible and Untraceable payment terms.

4. Good after-sale service.

5. We offer high quality products at competitive price in quick delivery.



Shipping Details:



SHIPPING

(Normally arrive port time in working days)

Destination Express/Courier SHIP BY SEA SHIP BY AIR SHIP BY EMS
DHL/FEDEX/UPS/TNT
North America 3~7 days 15~24 days 5~7 days 10~12 days
South America 3~7 days 15~25 days 5~7 days 10~12 days
European Countries 3~7 days 20~30 days 5~7 days 10~12 days
Africa Countries 3~7 days 40~50 days 5~7 days 10~12 days
The Middle East 3~7 days 15~25 days 5~7 days 10~12 days
Australia 3~7 days 10~15 days 5~7 days 10~12 days
