Nomex Aramid Industrial Filter Cloth / Air Filter Cloth Material 450GSM~650GSM

I'm Online Chat Now

Nomex Aramid Industrial Filter Cloth / Air Filter Cloth Material 450GSM~650GSM

China Nomex Aramid Industrial Filter Cloth / Air Filter Cloth Material 450GSM~650GSM supplier

Large Image :  Nomex Aramid Industrial Filter Cloth / Air Filter Cloth Material 450GSM~650GSM

Product Details:

Place of Origin: jiangsu
Brand Name: Filter

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Carton or Woven Bag
Delivery Time: 3~15 days
Payment Terms: 30% in advance,the balance against the copy of bill of Lading
Supply Ability: Supply 10000pcs filter bags per month
Contact Now
Detailed Product Description
Product Name: Nomex(Aramid)filter Cloth Applicable Industrie: Building Material Shops, Manufacturing Plant, Printing Shops, Costruction Works
Feature: Good Acid And Alkaline Resistance Material: Nomex(Aramid)Needle Felt
Weight: 450GSM~650GSM Size: Customized

Nomex(Aramid)filter cloth



Material:Nomex(Aramid)Needle Felt
Weight: 450GSM~650GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138, Φ 152, Φ 158 etc. We make it as your requirements.
Length: 1000mm~8000mm. We make is as your requirements.

Fibre Aramid
Scrim Aramid
Weight(G/M2) 450~550
Thickness (mm) 2.2
Width (mm) ≤ 2.2
Length 50m/roll
Finish treatment Singeing, Calendering, Heat-set
Air permeability (L/m2/s): 120~200
Tensile strength (N/5× 20cm) Warp:>1000 Weft:>1200
Tensile elongation (%): Warp:<50 Weft:<55
Temperature (ºC): Continue: 204 Instant: 240
Anti-acid Excellent
Anti-alkali Excellent
Anti-abrasion Excellent





Making method:

Our bags are sewn with 3 - needle chain stitch to ensure seam integrity. Top constructions consist of snap band, flange top, ring top, soft cuffs or raw edge. Bottom removal bags are constructed with a raw top or soft cuff. Top and bottom removal bag bottoms have disc bottoms that are sewn using an overlock (surge) stitch or lock stitch. A wear strip or custom skirts is attached to the bottom portion of the bag to prevent premature wear from bag-to-bag and bag-to-cage abrasion.
