FMQD Air Cleaning Industrial Dust Collector / Cement Dust Collector Novel Design

I'm Online Chat Now

FMQD Air Cleaning Industrial Dust Collector / Cement Dust Collector Novel Design

China FMQD Air Cleaning Industrial Dust Collector / Cement Dust Collector Novel Design supplier

Large Image :  FMQD Air Cleaning Industrial Dust Collector / Cement Dust Collector Novel Design

Product Details:

Place of Origin: jiangsu
Brand Name: filter

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Carton or Woven Bag
Delivery Time: 3~15 days
Payment Terms: 30% in advance,the balance against the copy of bill of Lading
Supply Ability: Supply 10000pcs filter bags per month
Contact Now
Detailed Product Description
Product: FMQD Air Cleaning Pulse Dust Collector Material Of Bag: Needle Felt, Glass Fiber, PTFE, FMS.
Work Principle: PLC Automatic Control Characteristics: Novel Design
Type: FMQD(PPC) Series Medium: Dry Dust

FMQD Air Cleaning Pulse Dust Collector



Introduction:



FMQD(PPC) series air box impulse bag dust collector is the first and best chioce for all major academy of design. This kind of dust collector has 3 series and 33 specifications.The filtering area can be from 93 to 4361 m3 , it’s processing capacity can be from 6900 to 314000m3/h . It has a seperator to clean the dust with the method of great specification impulse cleaning. It esp. appropriate for the processing with the powder in high concentration.



FMQD air cleaning dust collector advantages:


1 Strong ability to clean the dust

2 Good efficient and can be used for a long time

3 Simple processing with low investment

4 Tight structure and little covering area.

FMQD air cleaning dust collector operating principles:

Air with dust enters the middle and lower cabinet by air inlet of the dust collector, then into the upper cabinet through filter bag. The dust is seperated onto the filter bag that the air can go into the upper cabinet through the verturi tube and sent out from the air outlet. When the obstruction reach some degree that the impulse valve is started. The pressed air is injected into the corresponding filter bags through the verturi tube by holes of spray pipe. Filter bag expands that the dust falls, then the filter bag can be used again.













Type
Item
Air Volume(m3/h) Wind Speed(m/min) Filtration Area(m2) Filter Bag Quantity(piece) Resistance(Pa) Dust Content in Stack Gas(g/m3) Keep Warm Area(m2) Weight(kg)
32-3 6900 1.2~2.0 93 96 1470~1770 <1000 26.5 2880
32-4 8930 124 128 34 4080
32-5 11160 155 160 41 5280
32-6 13390 186 192 48.5 6480
64-4 17800 248 256 70 7280
64-5 22300 310 320 94 9960
64-6 26700 372 384 118 11640
64-7 31200 434 448 142 13320
64-8 35700 496 512 166 15000
