LCM Long Bag Industrial Dust Collector / Offline Reverse Pulse Dust Collector

I'm Online Chat Now

LCM Long Bag Industrial Dust Collector / Offline Reverse Pulse Dust Collector

China LCM Long Bag Industrial Dust Collector  / Offline Reverse Pulse Dust Collector supplier
LCM Long Bag Industrial Dust Collector  / Offline Reverse Pulse Dust Collector supplier LCM Long Bag Industrial Dust Collector  / Offline Reverse Pulse Dust Collector supplier

Large Image :  LCM Long Bag Industrial Dust Collector / Offline Reverse Pulse Dust Collector

Product Details:

Place of Origin: jiangsu
Brand Name: filter

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Carton or Woven Bag
Delivery Time: 3~15 days
Payment Terms: 30% in advance,the balance against the copy of bill of Lading
Supply Ability: Supply 10000pcs filter bags per month
Contact Now
Detailed Product Description
Product: Low Pressure Offline Dust Collector Material Of Bag: Needle Felt, Glass Fiber, PTFE, FMS.
Work Principle: PLC Automatic Control Characteristics: Novel Design
Filter Standard: Φ160 ×6050mm Concentration Of Emission: 50-100mg/m3

Low Pressure Offline Dust Collector



1. LCMseries pulse long bag dust collector is the company engineering and technical personnel in the injection pulse except for bag dust collector.

Based on the technology of dust, and to meet the wind volume of flue gas purification needs of low pressure pulse bag dust collector. It has not only than the sail cloth bag dust remover deashing ability, high dust removal efficiency, emission concentration is low, but also has stable and reliable, low gas consumption, covers an area of small features, particularly suitable for processing large amount of flue gas . JDMC series low-voltage long bag pulse filter in the world has been widely used, in foreign countries also has a large number of use, promotion, and can be widely used in cement, metallurgy, petrochemical, building materials, food, machinery, electric power, carbon black, garbage, industrial furnace high temperature dust gas purification and dust-shaped materials recovery. This product is integrated sectional reverse blow and pulse cleaning dust remover has the advantages of two types, overcame sectional reverse blow ash strength is insufficient and the general pulse cleaning dust attached such shortcomings, the cleaning efficiency, injection frequency is greatly reduced. The use of the product drowned pulse valve, reducing the blowing air pressure and energy consumption of equipment in operation, prolongs the service life of the valve bag filter, pulse, comprehensive technical performance in improving.



2. Performance characteristics



The novel design, the air intake structure, coarse particles of a high temperature falls into the ash hopper directly, effectively protects the filter bag. Use of long bag, under the same processing power equipment covers an area of small, more convenient for the transformation of the old factory. Use divided chamber off-line cleaning, high efficiency, two times less dust adsorption, and effectively reducing the energy consumption of the equipment, the filter bag with a pulse valve fatigue degree is reduced accordingly, increase the filter and valve life, reduce the number of equipment operation and maintenance costs. The maintenance for bag can not stop system fan, the normal operation of the system under the conditions of divided chamber. The bag mouth adopts a spring tensioning structure, convenient disassembly and assembly, good sealing performance. The box body through the gas tightness design, and kerosene leak detection, maximum extent possible to reduce air leakage. The whole device by the PLC machine control, automatic cleaning, unloading, automatic temperature control and temperature







Dust Collector Bag Filter Specification:



Type
Item
1850 2300 2800 3700 4600 5500 6500 1850×2 2300×2 2800×2 3700×2
Filtration Area(m2) 1850 2300 2800 3700 4600 5500 6500 3700 4600 5600 7400
Air Volume(m3/h) 16.2 20.7 25.2 33.3 41.4 49.5 58.5 33.3 41.4 50.4 66.6
Filter Bag Quantity(piece) 616 770 924 1232 1540 1848 2156 1232 1540 1848 2464
Filter standard(diameter×length) Φ160 ×6050mm
Deashing Method Offline Deashing
Amount of offline room(piece) 4 5 6 8 10 12 14 8 10 12 16
Air Leak Percentage(%) ≤2%
Inlet Gas Concentration(mg/m3) ≤20g/m3
Concentration of Emission(mg/m3) 50-100mg/m3
Pulse Valve Quantity(piece) 44 55 66 88 110 132 154 88 110 132 176
Size of Outside (length×width×height)(mm) 11500×
5500×
13800
13800×
5500×
13800
16560×
5500×
13800
22080×
5500×
13800
27600×
5500×
13800
33120×
5500×
13800
38640×
5500×
13800
11500×
10300×
13800
13800×
10300×
13800
16560×
10300×
13800
22080×
10300×
13800
