PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance

I'm Online Chat Now

PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance

China PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance supplier
PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance supplier PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance supplier PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance supplier

Large Image :  PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance

Product Details:

Place of Origin: jiangsu
Brand Name: Filter
Model Number: fibreglass filter bag

Payment & Shipping Terms:

Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Carton or Woven Bag
Delivery Time: 3~15 days
Payment Terms: L/C, D/A, D/P, T/T, Western Union
Supply Ability: Supply 10000pcs filter bags per month
Contact Now
Detailed Product Description
Product Name: FMS With PTFE Membrane Fibreglass Filter Bag Usage: Industry Dust Collector
Weight: 800GSM Size: Customized
Type: Pocket Filter,Dust Filter Bag,reverse Air Usage: Dust Filter,Air Filter,steel,carbon Black
Material: Fiberglass,PTFE Application: Industry Dust Collector,Cement Plant,dust Filter Bag For Cemet Factory And So On,Dust Filter
Shape: Long Tube With Steel Ring,Round Or Customized Working Temperature: 280 Degree
Thickness: 1.8-2.8mm Temperature: 130-300 Deg.
Sample: Free Feature: High Temperature Resistance,Large Dust,High Quality,High Efficiency,Dust Collection
Oem: Yes

FMS Fibreglass with PTFE membrane Filter Bag

Description:



Material: FMS filter cloth
Weight: 800GSM
Diameter: Φ 120,Φ 130, Φ 135,Φ 138, Φ 152, Φ 158 etc. We make it as your requirements.
Length: 1000mm~8000mm. We make is as your requirements.



Specification:



Fibre Fibreglass
Scrim Fibreglass
Weight(G/M2) 800
Thickness (mm) 2.2
Width (mm) ≤ 2.2
Length 50m/roll
Finish treatment Singing,Calendering,with PTFE membrane treatment.
Air permeability (L/m2/S): 150~300
Tensile strength (N/5× 20cm) Warp:>1700 Weft:>1800
Tensile elongation (%): Warp:<10 Weft:<10
Temperature (ºC): Continue: 260 Instant: 300
Anti-acid Excellent
Anti-alkali Fair
Anti-abrasion Excellent
Hydrolytic stability Fair
Application Mainly used in Steel Plant,Non-ferrous melting,Chemical,Carbon black and Building metails.



Product Feature:



1.High temperature resistance.
2.Good anti-acid/anti-alkali capacity.
3.Excellent anti-abrasion capacity.
4.High filtration efficiency.
5.Good raw material, competitive price.
6.Fast delivery.
7.Size can be customized.



Application:



1. Steel Plant.

2. Cement Plant.

3. Combustion.

4. Coal burning boiler.

5. Waster incineration.

6. Carbon black producing.



Making method:



Our bags are sewn with 3 - needle chain stitch to ensure seam integrity. Top constructions consist of snap band, flange top, ring top, soft cuffs,antiskid rop or raw edge. Bottom removal bags are constructed with a raw top or soft cuff. Top and bottom removal bag bottoms have disc bottoms that are sewn using an overlock (surge) stitch or lock stitch.Usually it have 7 supporting rings.



Packaging & Delivery:



PTFE Membrane Fiberglass Filter Bag 800GSM High Temperature Resistance



Competitive Advantages:



1. 100% custom pass guaranteed.
2. Our products have been exported to Germany, Norway, Poland, Finland, Spain, UK, France, Russia, USA, Brazil, Mexico, Australia, Japan, Korea, Thailand, Indonesia, Uruguay and many other countries.
3. Flexible and Untraceable payment terms.
4. Good after-sale service.

5. We offer high quality products at competitive price in quick delivery.



Shipping Details:



SHIPPING

(Normally arrive port time in working days)

Destination Express/Courier SHIP BY SEA SHIP BY AIR SHIP BY EMS
DHL/FEDEX/UPS/TNT
North America 3~7 days 15~24 days 5~7 days 10~12 days
South America 3~7 days 15~25 days 5~7 days 10~12 days
European Countries 3~7 days 20~30 days 5~7 days 10~12 days
Africa Countries 3~7 days 40~50 days 5~7 days 10~12 days
The Middle East 3~7 days 15~25 days 5~7 days 10~12 days
Australia 3~7 days 10~15 days 5~7 days 10~12 days
